Bettermaker Mastering Equalizer

Bettermaker Mastering Equalizer Product Features:

– 399 presets with unique names, total recall, A/B comparison

– 5-inch capacitive touchscreen with back-light, four encoders with push-button action for ease of control

– stereo, dual-mono and mid/side operation modes with focus function

– stereo 12 or 24dB/oct high-pass filter with adjustable cutoff frequency (10Hz – 250 hz; extended to 6Hz with the resonance enabled)

– four stereo parametric filters with 15dB boost/cut range, variable Q (0.2 – 7):

– EQ1: 22Hz – 470Hz (bell/shelf)

– EQ2: 90Hz – 2kHz (bell)

– EQ3: 480Hz – 10kHz (bell)

– EQ4: 1kHz – 23kHz (bell/shelf)

– stereo passive equalizer with extended hi-boost section (air bands – 20 and 28 kHz)

– stereo, 12dB/oct low-pass filter with adjustable cutoff frequency (2 – 38 kHz)

– adjustable output level (+/- 10dB)

– Frequency Search, Gain Lock and Auto-Q functions

– on-board measurement of PEAK/RMS levels and RTA analyzer

– on-screen live representation of the equalization curve

Bettermaker Mastering Equalizer Technical Specifications:

Technical specification (all filters enabled, set flat):

– Frequency response 20Hz to 20kHz (+/- 0.2 dB);

– Dynamic range: 129 dB @ +18 dBu, 20 kHz BW

– THD+N: 0.023% @ +4 dBu, 0.1% @ +18 dBu, 20-20 kHz, unity gain, 20 kHz BW

– CMRR: max 80 dB @ 3 kHz, min 55 dB @ 50Hz, 20 kHz BW

– Crosstalk: min -110 dB @ 30Hz, max -65 dB @ 20kHz, +18 dBu, 20 kHz BW

– balanced stereo input (XLR), 23dBu max input level (THD < 0.1%)

– balanced stereo output (XLR), 23dBu max output level (THD < 0.1%)

– Operating Level: +4dBu

– Input impedance (differential): 48kΩ (for balanced signal)

– Output Impedance: 50Ω + 50Ω (electronically balanced)

– 2U enclosure, 230mm deep

– 115/230V switch

– advanced linear power supply with toroidal AC mains transformer

– Maximum power consumption: 20W

– Shipping weight: 5.5 kg
