CIOKS

CI-AC10

CIOKS AC10 Power Supply

The Cioks AC10 is a dedicated multi-output power supply for effect pedals. If you have one or two pedals in your setup which require an AC power source, AC10 is the right choice.


    • Cioks AC10 PRODUCT FEATURES:

      It powers all vacuum tube pedals from Electro-Harmonix, Kingsley, older Blackstar HT series, the Whammy or JamMan from DigiTech, Tube Rotosphere, Tubeman, Tube Factor or Replex from Hughes & Kettner or EBS Valve Drive just to mention a few. If you only have one AC pedal, you can convert one of the AC sections into a powerful DC section offering 600mA with voltages 9, 12 and 15V DC. The first 4 isolated outlets offering a total of 600mA are ideal for pedals using 9 or 12V DC at lower currents op to 200mA.

      Features:

      • 10 outlets configured in 6 isolated sections
      • toroidal transformer with additional magnetic field shielding
      • 2 powerful AC sections with 800mA each
      • 9, 12 and 16V AC available
      • one AC section convertible into a 600mA DC section
      • 15V option for Radial Tonebone pedals
      • short circuit protection of all outlets
      • advanced LED monitoring of each section
      • temperature monitoring
      • 120 or 230V mains voltage operation
      • detachable mains power cord
      • a total of 16 Flex cables included
      • Flex cable for Electro‑Harmonix vacuum tube pedals from included
      • one Split Flex and one Stack Flex for 18V pedals also included
      • mounting bracket included
      • durable steel enclosure with 2mm thick top
    • Cioks AC10 TECHNICAL SPECIFICATIONS:

      Specifications:
      Outlet 1-2:    9V DC / 100mA each
      Outlet 3-4:    9 or 12V DC / 200mA each
      Outlet 5-6:    9 and 12 or 15V DC / 600mA*
      Outlet 7-8:    9 or 12V AC / 800mA*
      Outlet 9-10:  9, 12 or 16V AC / 800mA
      * only one of these two sections can be used

      Size: 158x98x35mm (excl. detachable rubber feet)
      Weight: 1,1kg

      Warranty period: 5 years worldwide

Need more info on the AC10 Power Supply? Click HERE for the official Cioks product listing >>>
