Specifications
| Directional pattern: | Supercardioid |
|---|---|
| Principle of operation: | Pressure gradient |
| Cartridge Type: | Pre-polarized condenser |
| Frequency range: | 20 Hz to 20 kHz |
| Frequency range, ± 2 dB: | 40 Hz - 18 kHz |
| Sensitivity, nominal, ± 2 dB at 1 kHz: | 12 mV/Pa; -38.4 dB re. 1 V/Pa |
| Equivalent noise level, A-weighted: | Typ. 16 dB(A) re. 20 µPa (max. 19 dB(A)) |
| Equivalent noise level, ITU-R BS.468-4: | - |
| S/N ratio (A-weighted), re. 1 kHz at 1 Pa (94 dB SPL): | Typ. 78 dB(A) |
| Total Harmonic Distortion (THD) at 1 kHz: | < 1 % up to 137 dB SPL peak |
| Dynamic range: | Typ. 121 dB |
| Max. SPL, peak before clipping: | 150 dB |
| Output impedance: | 100 ohm |
| Minimum load impedance: | 2 kΩ |
| Cable drive capability: | 100 m (328 ft) |
| Output balance principle: | Impedance balancing with Active Drive |
| Common Mode Rejection Ratio (CMRR): | > 60 dB |
| Power supply (for full specifications): | 48 V Phantom power (± 4 V) |
| Current consumption: | 2.8 mA |
| Color: | Matte black |
| Weight: | 58 g (5.6 oz) |
| Diameter: | 19 mm (0.75 in) |
| Capsule diameter: | 19 mm (0.75 in) |
| Output voltage, RMS: | 4.5 V |
| Microphone Length: | 64 mm (2.5 in) |
| Polarity: | +V at Pin 2 for positive sound pressure |
| Connector: | XLR-3M. Pin 1: shield, Pin 2: signal + phase, Pin 3: - phase |
| Matching tolerance: | ± 1 dB |
| Temperature range: | < 10 °C |
