$284.95$389.00
RA-PROD2
Radial Engineering ProD2 Stereo Direct Box
The Radial ProD2 is a compact stereo direct box developed by Radial Engineering to address the needs and challenges of interfacing a stereo keyboard to a professional audio system. This passive DI design features two independent channels with separate inputs and thru-puts for the artist's stage amplifier and also features two fully isolated outputs for the main PA system.
Type: DI Boxes
Radial ProD2 PRODUCT FEATURES:
- Stereo direct box designed for keyboards
- Provides a smooth, warm sound that rounds out digital edge
- Handles huge transients without choking
- Can be rack mounted for touring rigs
Radial ProD2 TECHNICAL SPECIFICATIONS:
| Specifications | RADIAL ProDI |
|---|---|
| Audio circuit type: | Passive, transformer based |
| Number of channels: | Single channel (mono) |
| Frequency response: | 20Hz ~ 18.5KHz (± 0.2dB) |
| Dynamic range: | 128dB |
| Maximum input: | +18dB @ 20Hz |
| Total harmonic distortion: | 0.01% from 20Hz~20kHz @-10dB |
| Phase deviation: | 1° @ 100Hz; 8° @ 20Hz |
| Input impedance: | 140k Ohms, unbalanced |
| Output impedance: | 150 Ohms, balanced |
| Features | |
| Transformer: | Eclipse ET-DB2, 12:1 ratio |
| Shield: | Faraday, mu-metal can |
| Input pad: | -15dB |
| 180° polarity reverse: | Inverts absolute phase |
| Ground lift: | Disconnects pin-1 at XLR output |
| XLR configuration: | AES standard (pin-2 hot) |
| Connectors: | 1/4" in & thru, XLR-M out |
| General | |
| Construction: | 14 gauge steel chassis & outer shell |
| Finish: | Durable powder coat |
| Size: (W x H x D) | 70 x 108 x 44mm (2.75” x 4.25” x 1.75") |
| Weight: | .54kg (1.2lbs) |
| Shipping Size: W x H x D: | 102 x 76 x 165mm (4.00" x 3.00" x 6.50") |
| Shipping Weight: | 0.61 kg (1.35 lbs) |
| Power: | Passive, no power required |
| Conditions: | For use in dry locations only between 5°C and 40°C |
| Warranty: | Radial 3-year, transferable |
| Specifications are subject to change without notice. | |
