With the Minilogue XD delivers a next-generation analog synthesizer for a new generation of musicians new to analog synthesis. In addition to emphasizing the same real analog sound and joy of controlling an electronic musical instrument offered by the original minilogue, the Minilogue XD newly adds a digital multi-engine, effects, a powered-up sequencer, and micro tuning functionality, further expanding the possibilities for sound design and performance potential.
Digital multi-engine provided as a third oscillator in addition to the two analog VCOs.
This engine is equipped with three different types of sound generator (noise, VPM, and user slot)
Polyphonic step sequencer controlled by 16 buttons
Micro tuning function featured on the monologue, allowing you to individually adjust the pitch of each key.
23 preset tunings are built-in that include some created by Aphex Twin and Dorian Concept, and users can also create and store six user scales
Joystick controls pitch bend and modulation depth, etc. A desired parameter can also be assigned to the up/down axis
Two CV IN jacks are provided, with voltage levels of -5V–+5V
A stereo effect unit is provided at the final stage, and the output jacks are now also stereo.
Keyboard: 37-keys (Slim-key, velocity sensitive)
Sound Generation: Analogue sound generator + Multi digital sound generator (Noise, VPM, User)
Maximum Polyphony: 4 voices
Programs: 500 voices (more than 200 preload, 300 user programs)
Voice Mode:4 (POLY, UNISON, CHORD, ARP / LATCH)
Sequencer: 16-step polyphonic sequencerI
Input/Output connectors: Headphone jack (Stereo phone jack), OUTPUT L/MONO, R jacks (monaural phone jack unbalanced). CV IN 1, CV IN 2 jacks (3.5 mm [1/8"] monoural mini jack, Input voltage: -5 V – +5 V (Modulation mode), -3V – +5 V (CV/Gate mode), SYNC IN jack (3.5 mm [1/8"] mini jack, maximum input level 20 V), SYNC OUT jack (3.5 mm [1/8"] mini jack, output level 5 V), MIDI IN jack, MIDI OUT jack, USB B jack, DAMPER jack (half damper is not supported)
