The LEGEND ’70s introduces the new concept of MODULAR STAGE PIANO that allows you to customize the instrument according to your needs. The superb sound quality, thanks to the unique VISCOUNT PM (Physical Modeling) technology and the accurate response of the keyboard, combined into a portable instrument of the highest quality.
The new LEGEND ’70s offers an unprecedented ability to customize your instrument with several Sound Modules equipped with state-of-the-art Sound Generators, including physical modeling. The Modules can be easily positioned and swapped on the front panel, according to your personal musical needs.
Currently the following modules are available to enhance the piano:
A.PIANO MODULE
CLAVI MODULE
EXTERNAL MODULE
SYNTH-8 MODULE
Others will be available in the future in “Always Growing” family.
| Keyboard | – Compact: 73 Keys, Hammer action, velocity sensitive with triple sensor – Artist: 88 Keys, Hammer action, velocity sensitive with triple sensor – Artist-W: 88 Keys, Graded hammer action, wooden keys, velocity sensitive with triple sensor |
|---|---|
| Touch Sensitivity | Very light, Light, Normal, Hard, Very hard, Fixed |
| Keyboard mode | Each sound module can be assigned to a programmable keyboard zone. Two zones in Split Mode with a programmable Split Point |
| Technology | – Physical Modeling (PM): E.Piano module – High Definition Sampling (HDS): Sound Collection module |
|---|---|
| Sounds | – E.Piano module: 8 E.Pianos (5 Rhod, 2 Wurli, 1 E.Grand) – Sound Collection module: Pad, Strings, Choir, Brass, Keyboard, Organ, Bass, Guitar, Bells, Marimba and other for a total of about 100 sounds |
| Polyphony | – Full: E.Piano module – 128: Sound Collection module |
| Transposer | +/- 12 Semitones, +/- 48 for each module |
| Fine Tuning | 427,5 Hz – 452,9 Hz (adjustable in 100 step) |
| Insert Effects | Effects 1 & 2 can be used in series or in parallel: Tremolo, Vibrato, Chorus, Flanger, Phaser, Wah-wah, Amp, Rotary, Delay, Equalizer, Compressor |
|---|---|
| Reverb | Small/Large Room, Small/Medium/Large Hall, Stage1/2, Medium/Large Plate, Spring1/2, Tape1/2 |
| Master EQ | 3 bands (with programmable parameters) |
| Controls | Modulation Wheel, Pitch Wheel |
|---|---|
| Display | Main display 128×64 oled – 7 segments depending on the sound module |
| Data Memory | – Program Mode: 16 Banks with 16 Programs each – Song Mode: 9 Lists of 40 Songs with 4 Programs each |
| Connections | Main Audio Out L(Mono)/R, Aux Audio Out 1/2, Audio In, MIDI In/Out, USB to Host / to Device, Foot Controller 1/2, Foot Switch 1/2, Sustain, Program +/-, Headphones |
| USB to Host | MIDI over Usb, AUDIO over Usb, Editor |
| USB to Device | Load and save data on a Pen drive, Battery charger |
| Power Supply | AC100/240V |
|---|---|
| Included accessories | Power cord, Sustain Pedal, Music Rest, User Manual |
| Optional | Metal Stand, Softbag for Keyboard, Softbag for Stand |
| Dimensions (WxHxD) | – Compact: cm 112 x 18 x 47,5 / 44” x 7” x 18,7” – Artist / Artist-W: cm 133 x 18 x 47,5 / 52,3” x 7” x 18,7” |
| Weight | – Compact: Kg 16,2 / Lbs 35,7 – Artist: Kg 18,8 / Lbs 41,4 – Artist-W: Kg 19,5 / Lbs 42,9 |
| The new VISCOUNT LEGEND ’70s stage piano, designed and engineered in Italy, provides incredible expressive capabilities with a customizable interface in a perfect portable solution. The combinations of easy-to-use powerful sound modules in a compact and vintage cabinet offers to exigent musicians an instrument without any compromise. |
| The LEGEND ‘70s introduces, for the first time, the concept of MODULAR STAGE PIANO. According to your needs, you can now choose the right combination of sound generating modules with dedicated knobs and buttons. Currently the modules ELECTRIC PIANO, ACOUSTIC PIANO, CLAVI and SOUND COLLECTION are available, while many others will be available in the future, within the “ALWAYS GROWING” family. Moreover to the standard PROGRAM and EFFECTS modules an optional EXTERNAL module is availabe to making the instrument flexible and very powerful. |
| The design of the LEGEND ‘70s Hammer Action Keyboard perfectly matches the instrument’s sound generators. The 3 contact sensors, under each key, are able to detect the corresponding movement with the highest precision.
For the more demanding musician the LEGEND ‘70s Artisit-W also offers a graded hammer arrangement where their weight becomes lighter as you climb up the keyboard. In addition, as with the traditional acoustic grand piano, the Legend Artist-W keyboard is enhanced with real wood piano keys. These keys are made of carefully selected and seasoned wood to eliminate any defect or deformation and provide maximum uniformity and stability over time. |
| Each module installed in the LEGEND ‘70s piano has its own sound generator specially designed to reproduce its sound set. This arrangement gives a great advantage over the whole instrument polyphony, avoiding the “sound generator processor share” that affects all the competitors sampled pianos when many sounds are played in at the same time.
The ACOUSTIC PIANO and SOUND COLLECTION modules are powered by HDS (High Definition Sampling) technology characterized by the detailed sampling of acoustic instruments and the ability to reproduce the entire dynamic range of each instrument. The ELECTRIC PIANO and CLAVI modules are powered by Viscount’s patented Physical Modeling (PM) technology which, through complex mathematical algorithms, is able to reproduce with absolute fidelity the dynamic and physical-acoustic phenomena of the electric piano, giving you the most expressive and authentic performing experience ever. Experienced musicians know very well that almost all pianos on the market, using the sampling technology, suffers from the “Slicing Problem”, because, for specific groups of keys and dynamic range, they use the same sample! This approximation causes an annoying timbre discontinuity. Viscount PM technology does not have this problem at all, since, for each key and dynamic level, the sound is perfectly calculated through the precise mathematical model of the real instrument. |
| The LEGEND ‘70s is equipped with a full set of modern connections. |
