RA-Reamp-JCR
Radial Engineering Reamp JCR Studio Reamper
The Radial Reamp JCR is a passive Re-amper that allows you to take a pre-recorded track from your DAW and send it back to a guitar or bass amplifier to re-record it. Instead of worrying about the sound of your track, you can focus your attention on getting the best musical performance first while tweaking the sound on your amp later. Once you have captured the magic, you can send the guitarist home and Reamp the track at will as you move your microphones around the room, and also try various amplifiers or introduce new effects.
FEATURES
- Re-record tracks through a guitar or bass amp after the initial recording
- The Original Reamp circuit designed by the legendary John Cuniberti
- Plug and play easy to uses passive design
- Improve your productivity while expanding creative options after the initial recording.
SPECIFICATIONS
| Specifications | |
|---|---|
| Specifications are subject to change without notice. | |
| Audio circuit type: | Passive, transformer isolated |
| Frequency response: | 20Hz ~ 20kHz (+0dB/-1dB) |
| Common mode rejection ratio: | -55dB @ 55Hz |
| Dynamic range: | 140dB |
| Noise floor: | -115dBu |
| Maximum input: | +26dBu |
| Total harmonic distortion: | 0.001% @ 1kHz/0dBu input |
| Inter-modulation distortion: | 0.0025% @ 1kHz/-10dB input |
| Phase deviation: | 2º @ 100Hz; 0º @ 800Hz |
| Input impedance: | 1800 Ohms |
| Output impedance: | 4.8k Ohms |
| Features | |
| XLR input: | Balanced line-level, AES standard (pin-2 hot) |
| Ground lift: | Disconnects pin-1 at the XLR input |
| Mute: | Mutes the output at the ¼" unbalanced out |
| Output level: | Adjustable |
| Hi-cut filter: | Hi-cut: -3dB down @ 1kHz |
| Low-cut filter | Low-cut: -3dB down @ 180Hz |
| Polarity: | 180º polarity reverse at ¼" output |
| General | |
| Power: | Passive, no power required |
| Construction: | 14 gauge steel chassis & outer shell |
| Finish: | Durable powder coat |
| Size: | 3.3" x 5.0" x 2" (84 x 127 x 48mm) |
| Weight: | 1.32lb (600g) |
| Shipping Size: | 4" x 3" x 6.5" ( 102 x 76 x 165mm) |
| Shipping Weight: | 1.85lb (840g) |
| Conditions: | For use in dry locations only between 5°C and 40°C |
| Warranty: | Radial 3-year, transferable |
Type: Reamping
