Audio-Technica

AT ATM230

Audio-Technica ATM230 Hypercardioid Dynamic Instrument Microphone

The Audio-Technica ATM230 is a high-quality dynamic hypercardioid microphone optimised to handle high levels of SPL. The ATM230 is ideal for drums & percussion - especially kick drum or other low frequency sound sources. The hypercardioid polar pattern is ideal for focussing the capture area, and the proprietary capsule excels in recording low-frequencies with exceptional warmth and transparency. With it’s tough metal construction and included travel-pouch and mount, the ATM230 is equally useful live and in the studio.


    • ATM230 PRODUCT FEATURES:

      Hypercardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source

      Handles very high SPL at close range

      Big, warm low-frequency response with excellent attack

      Low-profile design permits versatile placement around drum kit

      Rugged, all-metal design and construction

      Includes AT8665 drum mount and a soft protective pouch

    • ATM230 TECHNICAL SPECIFICATIONS:

      ELEMENT
      Dynamic
      POLAR PATTERN
      Hypercardioid
      FREQUENCY RESPONSE
      30-12,000 Hz
      OPEN CIRCUIT SENSITIVITY
      –54 dB (1.9 mV) re 1V at 1 Pa
      IMPEDANCE
      600 ohms
      WEIGHT
      292 g (10.3 oz)
      DIMENSIONS
      82.5mm long, 38mm maximum diameter
      OUTPUT CONNECTOR
      Integral 3-pin XLRM-type
      ACCESSORIES
      AT8665 drum mount for 5/8″-27 threaded adapter; 5/8″-27 to 3/8″-16 threaded adapter; soft protective pouch
      AUDIO-TECHNICA CASE STYLE
      R2

Need more info on the ATM230? Click HERE for the official Audio-Technica product listing >>>
