Audio-Technica ATW-T1006 - Boundary Microphone/Transmitter for System 10 PRO

The Audio-Technica ATW-T1006 is a wireless boundary microphone, designed to synchronise with any System 10 or System 10 Pro wireless system by Audio-Technica.


    • Audio-Technica ATW-T1006 PRODUCT FEATURES:

      Cardioid condenser boundary microphone/transmitter pairs with any System 10 or System 10 PRO digital wireless receiver
      Digital 24-bit/48 kHz wireless operation for ultimate sound quality and dependable performance
      Operates in the 2.4 GHz range – completely free from TV interference
      User switch can be set to toggle between talk and mute modes, or function as a press-to-talk or press-to-mute button
      Gain Control switch allows selection of three input gain levels: -6 dB (for loudest voices), 0 dB and +6 dB (for softest voices)
      Two red/green LEDs – one visible from the front of the unit, the other from the rear – indicate toggle/talk/mute mode, battery level, and charging status
      Switchable low-cut filter
      System ID Display located on bottom of unit
      Automatic frequency selection for seamless, interference-free operation
    • Audio-Technica ATW-T1006 TECHNICAL SPECIFICATIONS:

      Maximum Input Sound Level

      139 dB SPL

      RF Power Output

      10 mW

      Spurious Emissions

      Following federal and national regulations

      Power Supply

      100-240V AC (50/60 Hz) to 5V DC 0.5A switched mode external USB-type power supply

      Battery

      3.7V rechargeable lithium-ion battery

      Battery Life

      9 hours

      Charging Time

      Approx. 4.5 hours (for 0-100% charge)

      Switches

      Touch-sensitive, capacitive-type user switch function: toggle (talk on power up), momentary on, momentary off; Low-cut filter: flat, roll-off; Gain: -6 dB, 0 dB, +6 dB

      Dimensions

      96.8mm W × 38.0 mm (1.50″) H × 122.8 mm (4.83″) D

      Net Weight

      415g

      Accessories

      AC Adaptor (USB-type), USB charging cable
