CO2-8WD-BE

Point Source Audio Dual Element Headset Microphone

Color
Beige
Brown
Black
 More payment options

Pickup available Artarmon - In Store Unless product is on backorder/preorder

Usually ready in 2 hours
Or Rent From
$15.00 per weekReturn any time after minimum rental agreement

The award-winning SERIES8 omnidirectional headsets provide you with absolute confidence in fitting and microphone placement—and now even more so with fully redundant elements that are factory matched and mated into an ultra-low-profile tandem form factor. Both elements are IP 57 waterproof rated against water, sweat, and makeup; and our super bendable boom on this headset is “Unbreakable” up to 360°.  Each microphone accepts two interchangeable X-Connectors for termination to your wireless systems.

Features

  • 2 MICS IN ONE: Dual matched waterproof elements for built-in redundancy
  • "Unbreakable Boom" bends 360°
  • 136 dB max SPL
  • IP 57 waterproof rated
  • Interchangeable X-Connectors for all popular wireless packs including Shure, Sennheiser, and Audio-Technica
  • Mic element only 3mm in diameter
  • Optimal gain before feedback
  • Available in colors beige, brown, or black

TWO MICS for the size of ONE

The headset microphone's patent-pending design offers built-in microphone redundancy with the convenience of a single cable. The elements are factory matched to a near-identical ±0.5 dB difference—and both elements are waterproof. The mic elements are offset to reduce mass and effectuate a sleek profile.

The mic cable splits approximately nine inches above connection to the body-packs to allow ample room for separation of the transmitters.

Wears Left or Right

Ear hooks fold flat for protection in storage and travel.
Like our original single element headset microphone, the CO2-8WD features the unique ability to reverse for left or right ear wearing to accommodate any mic user or production requirement.

Specifications

Element: Waterproof Back Electret Condenser (2 Matched)
Pattern: Omnidirectional
Frequency: 20Hz - 20kHz
Sensitivity: -43 dB 1V/Pa (± 3dB at 1kHz)
Maximum SPL: 136 dB SPL
Output Impedance: 1400 Ω (at 1kHz)
Operating Voltage: 1 - 10 V
Cable Length: 6 ft . + connector
Net Weight: 0.6 oz
Colors: Beige, Brown or Black
Connector Types: TA3F, TA4F, TA5F, lockable 3.5mm, Hirose, Lemo-style

Polar Response

CO-8_polar_response

Frequency Response

CO-8_frequency_response
