Drawmer

DRA-1976

Drawmer 1976 Stereo Three Band Saturation and Width Processor


Please contact me with information about availability and pricing for Drawmer 1976 Stereo Three Band Saturation and Width Processor




The 1976 3 band stereo saturation and width processor has been designed to inject character, colour & life into your recordings and live sound in a style endemic of the classic equipment of the 1970's. The completely analogue saturation of the 1976 will provide the realism that plug-ins can only aspire to, replacing the harsh, sterile digital sound with fullness, softness and warmth. Why emulate saturation when you can have the real thing?

Inspired by the highly acclaimed saturation and width features of the DC2476 Digital Mastering Processor the 3 bands of independent saturation of the 1976 have been designed to add the pleasing imperfections that are so endemic in classic gear. Saturation is ideal for adding fullness to your music, taking your music from a cold, bleak landscape to a warm, bright vista.

In addition, however, unlike conventional saturation products the 1976 also features 3 bands of stereo width control to really bring out the depth and add real presence to your mix, and all with a single, yet comprehensive set of controls that provide genuine stereo operation.



    • Product Features:

      Powerful 3 Band all Analogue Saturation for adding warmth to both your digital and analogue sounds.

      Designed to Inject character to your audio reminiscent of 1970's era gear and remove the sanitized harshness that digital recordings suffer from

      3 band fully adjustable Stereo Width provides controllable depth and presence to you mix.

      Fully Variable Crossover controls between the bands allows you to tune in to signals for different amounts of independent saturation across the full frequency range.

      Genuine stereo operation with one set of controls for both channels.

      Can operate in Stereo and Mono.

      The Mono switch helps highlight problems within the stereo mix.

      Internal Low Hum Toroidal Linear Power Supply with Voltage Selector Switch.

      Classic Drawmer Build Quality with Rugged Steel Chassis and aluminium Front Panel.

      Designed and manufactured by Drawmer in the UK.

    • Technical Specifications:

      INPUT:

      Input Impedance 20k Ohms or greater

      Maximum Input Level +18dBu


      OUTPUT

      Output Impedance <100 Ohms

      Maximum Output Level +21dBu into 10k Ohms Load


      FREQUENCY RESPONSE

      20Hz to 20kHz +/-0.2dB

      % DISTORTION (THD & NOISE) @ 1kHz

      0dB (ref +4) 0.006%


      POWER REQUIREMENTS

      230Volt or 115V at 50-60hZ, 15VA


      FUSE RATING

      T160mA for 230Volt,

      T315mA for 115Volt

      Conforming to IEC 127-2

      FUSE TYPE

      20mm x 5mm, Class 3 Timed-Blo, 250Volt working


      CASE SIZE

      482mm (W) x 44mm (H) x 202mm (D)


      WEIGHT

      2.6Kgs
