JBL

JBL-LSR305MKII

JBL LSR 305P MkII - Powered 5" Two-Way Studio Monitor (SINGLE)

The JBL LSR 305P MkII is a bi-amped two-way active studio reference monitor, featuring a 5-inch low-frequency driver and 1-inch tweeter. The 305P replaces the popular LSR 305 monitor, and feature next-gen JBL transducers that vastly improve transient response stereo imaging.


    • JBL LSR 305P MkII PRODUCT FEATURES:

      Patented Image Control Waveguide for detailed imaging and a broad, room-friendly sweet spot
      Next-generation JBL transducers for optimized transient response and improved linearity
      Patented Slip Stream™ low-frequency port for superior bass performance at all playback levels
      Dual integrated, custom Class-D amplifiers provide 82 watts of power for high output and dynamic range
      New Boundary EQ settings compensate for low frequency variants introduced by the environment
      HF Trim switch adjusts high-frequency output to room acoustics or personal preferences
      Flexible connectivity with balanced XLR and 1/4" TRS inputs, +4dBu / -10dBV input-sensitivity switch and adjustable volume control
      Engineered to JBL Linear Spatial Reference design criteria for outstanding accuracy in any working space
      Strenuous JBL 100-hour full-power test ensures years of reliability
      Sleek, modern design provides a visual upgrade to any studio
    • JBL 305P MkII  TECHNICAL SPECIFICATIONS:

      LF DRIVER SIZE: 203mm (5")
      HF DRIVER SIZE: 25mm (1")
      HF DRIVER TYPE: Soft dome
      CROSSOVER: 1725Hz 4th order acoustic Linkwitz-Riley

      POWER CONFIGURATION: Bi-amplified
      HF DRIVER POWER AMP: 41W, Class-D
      LF DRIVER POWER AMP: 41W, Class-D

      FREQUENCY RANGE (-10dB): 43Hz – 24kHz
      LOW FREQUENCY EXTENSION: (-10dB) 43Hz
      MAXIMUM CONTINUOUS SPL: 94dB
      MAXIMUM PEAK SPL: 108dB

      CABINET DIMENSIONS (H x W x D): 298 x 185 x 231mm
      NET WEIGHT: 4.73 kg
Need more info the JBL 305P MkII? Click HERE for the manufacturer's website >>>
