MOTU Micro Express 4x6 USB MIDI Interface

The MOTU Micro Express is a 4 x 6 MIDI interface designed for any Mac and Windows computer enabled with USB. Based on MOTU’s technology that landed them accolades - The Micro Express is a smaller, less expensive version of the MOTU MIDI Express XT, offering many of the same features. However, the Micro Express has the added advantage of being bus-powered and compact. The Micro Express offers 4 x MIDI inputs and 6 X MIDI outputs - 96 MIDI channels in total. Like the MIDI Express XT, the included ClockWorks™ software allows extensive merging, muting, and routing with the device, and along with SMPTE time code synchronization features, the MOTU Micro Express is an extremely cultivated MIDI interface given its size and price.

PRODUCT FEATURES:

• USB MIDI interface for Mac and Windows

• Stand-alone MIDI patch-bay/merger/processor (when powered via USB)

• SMPTE time code sync in all formats (includes new support for 23.976* fps time code)

• 4x6 MIDI merge matrix: connects any device to any other

• 16 front panel presets

• 4 independent MIDI IN

• 6 independent MIDI OUT

• 96 MIDI channels

• Supports MIDI Machine Control transport messages

• Pedal input for momentary footswitch

• 16 presets with 8 programmable, battery-backed memory

• MIDI Time Stamping (MTS) for sub-millisecond timing accuracy

• Includes updated drivers and ClockWorks™ software for Mac and Windows

• USB bus-powered

• MIDI and Sync

• MIDI processing

• Merge any inputs to any outputs

• Route any inputs to any outputs

• Mute any MIDI data on any cable

• Re-channelize on input and output

Synchronization

• SMPTE time code (LTC) generator and reader

• Converts LTC to MIDI Time Code (MTC) to sync a Mac, PC, or any other devices to SMPTE time code

• Converts all SMPTE frame rates (23.976*, 24, 25, 29.97 drop, 29.97 non-drop, 30)

• Stripes SMPTE time code in all frame rates (23.976*, 24, 25, 29.97 drops, 29.97 non-drop, 30)

• Converts MIDI Time Code to SMPTE time code

• SMPTE "Jam Sync" with adjustable freewheeling for dropout-free sync

• Supports MIDI Machine Control - serves as either an MMC master or slave, distributes MMC transport commands to all other MMC devices

**This feature is available only in micro express "re-release" models manufactured in 2011 or later**

• MOTU Micro Express 4x6 TECHNICAL SPECIFICATIONS:

• Custom-designed VLSI technology

• Front panel buttons and LED's for choosing presets (8 factories, 8 users)

• Front panel SMPTE stripe button

• Front panel SMPTE lock and tach LED's

• Status lights for MIDI IN/OUT and computers

• Front panel MIDI IN and OUT ports

• Panic button

• 10 MIDI connectors

• 2 SMPTE quarter-inch phone (line level)

• 1 pedal quarter-inch phone input

• Chassis dimensions, excluding rack ears: 9.5 x 7 x 1.75 inches (24.13 x 17.78 x 4.45 cm). With rack ears attached, fits one half of a standard 19 inch (48.26 cm) rack at 1U high.

SYSTEM REQUIREMENTS:

Includes software console for Mac and Windows, USB cable.

** Please note system requirements may change. For the most recent system requirements please visit the manufacturer's official product listing **
