Presonus

PRE-SL-32S

PreSonus StudioLive 32S 32-channel digital mixer and USB audio interface

1 IN STOCK

The StudioLive 32S is a powerful 32-channel mixer that provides the ultimate mixing experience, packing large format features into a small format chassis. Powered by the dual-core PreSonus FLEX DSP Engine, the StudioLive 32S digital mixer is equipped with 40 mixing channels, 26 mix buses, and 286 simultaneous processors—including 4 stereo reverberation systems, and Fat Channel plug-in models on every input channel and mix bus. With 128 (64x64) channels of USB recording, 128 channels of AVB network audio I/O, flexible routing options, and studio-grade audio quality, the StudioLive 32S delivers a fast and intuitive, surface-driven workflow for total control. Spend less time menu-diving and more time mixing—hands-on.

Product Features:

Powered by the new dual-core PreSonus FLEX DSP Engine to provide the most processing of any digital mixer in its class

40 input-channel digital mixer with 33 touch-sensitive motorized faders

32 local digitally controlled XMAX mic/line inputs

2 balanced stereo aux inputs

1 stereo tape input (RCA, Bluetooth, USB, AVB or SD)

4 FLEX FX returns

1 Talkback

26 mix buses

16 FlexMixes (Aux, Subgroup, Matrix)

4 dedicated FLEX FX buses

4 dedicated subgroups

Stereo Main bus

286 simultaneous processors

HPF

Gate / Expander

Compressor with Fat Channel plug-in models

4-band/6-band parametric EQ with Fat Channel plug-in models

Limiter

31-band Graphic EQ

4 FLEX FX slots featuring legendary classic reverb emulations and delays

State Space-Modeled Fat Channel compressor and EQ plug-ins available on every input channel and output bus

FLEX FX multi-effects processor with 4 slots to load legendary reverb emulations and delays with 4 dedicated effects buses

24 DCAs to control groups of channels

128-channel (64x64) recording over USB

Onboard multi-channel SD recorder (34x34) with true Virtual Soundcheck mode

AVB Networking onboard (64x64) to connect with other mixers, NSB-series stage boxes, EarMix 16M personal monitor mixers and more

User Profiles for managing multiple operators with custom permissions

Per channel digital patching from any analog, AVB, USB, or SD Card source

DAW Control

Advanced Studio One control integration

MCU emulation mode optimized for Logic

HUI emulation mode optimized for ProTools

Remote control every mix function from your computer, iPad, or Android tablet with UC Surface (included)

Put your musicians’ monitor mix under their fingers with QMix-UC (included) for iOS or Android

Capture 3.0 multitrack software included

Automated Virtual Soundcheck

Store StudioLive mix scenes with your audio

Advanced Studio One integration (Studio One Artist Included)

XMAX mic preamp control from Studio One

Control Fat Channel parameters from Studio One mixing console

Tech Specs:

Microphone Preamplifier

Input Type

XLR Female, balanced

Frequency Response to Main Output (at unity gain)

20-20 kHz, ±0.5 dBu

Input Impedance

1 kΩ

THD to Main Output

<0.005%, +4 dBu, 20-20 kHz, unity gain, unwtd

S/N Ratio to Main Output (Ref = +4 dB, 20 kHz BW, unity gain, A-wtd)

94 dB

Common Mode Rejection Ratio (1 kHz at unity gain)

65 dB

Gain Control Range (±1 dB)

0 dB to +60 dB

Maximum Input Level (unity gain)

+12 dBu

Phantom Power (±2 VDC)

48 VDC, switchable per channel

Line Inputs

Type

¼” TRS Female, balanced

Frequency Response to Main Output (at unity gain)

20-20 kHz, ±0.5 dBu

Input Impedance

10 kΩ

THD to Main Output

<0.005%, +4 dBu, 20-20 kHz, unity gain, unwtd

S/N Ratio to Main Output (Ref = +4 dB, 20 kHz BW, unity gain, A-wtd)

94 dB

Maximum Input Level

+18 dBu

Tape Inputs

Type

RCA Female, unbalanced (stereo pair)

Maximum Input Level

+12 dBu, ±0.5 dBu

XLR Outputs

Type

XLR Male, balanced

Maximum Output Level

+24 dBu, ±0.5 dBu

Output Impedance

100Ω

Line Outputs

Type

¼” TRS Female, balanced

Maximum Output Level

+18 dBu, ±0.5 dBu

Output Impedance

100Ω

Tape Outputs

Type

RCA Female, unbalanced (stereo pair)

Maximum Output Level

+18 dBu, ±0.5 dBu

Output Impedance

100Ω

Headphone Output

Type

¼” TRS Female, active stereo

Maximum Output

100 mW/ch. @ 60Ω load

Frequency Response

20 Hz – 20 kHz (± 0.5 dB)

THD+N

0.01%, 1 kHz, max gain, 20 Hz BW, unwtd

S/N Ratio

96 dB, 1 kHz, max gain, 20 Hz BW, unwtd

System Crosstalk

Input to Output

-90 dB (Ref = +4 dBu, 20 Hz-20 kHz, unwtd)

Adjacent Channels

-87 dB (Ref = +4 dBu, 20 Hz-20 kHz, unwtd)

Digital Audio and Control

ADC Dynamic Range

115 dB (A-wtd, 48 kHz)

DAC Dynamic Range

115 dB (A-wtd, 48 kHz)

USB Recording Port

USB 2.0, Type-B

Bluetooth™ Input

4.1, stereo

AES/EBU Output

XLR Male

Network Control Port

RJ-45

AVB Audio Network Port

Locking XLR Ethernet

Internal Processing

32-bit, floating point

Sampling Rate

48 kHz, 44.1 kHz

A/D/A Bit Depth

24

Reference Level for 0 dBFS

+18 dBu

Total System Latency

1.9 ms (local routing, analog in-analog out, all processing active)

Clock

Jitter

<20 ps RMS (20 Hz - 20 kHz)

Jitter Attenuation

>60 dB (1 ns in, 1 ps out)

Power / Environmental

Connector

IEC

Input-Voltage Range

90 to 230 VAC (±10%)

Power Requirements (continuous)

85W

Recommended Ambient Operating Temperature

0˚ to 40˚ Celsius / 32˚ to 104˚ Fahrenheit

Physical

Height

6.51” (165.36 mm)

Width

32.37” (822.21 mm)

Depth

22.97” (583.48 mm)

Weight

37.2 lbs. (16.9 kg)

  • System Requirements:

    Below are the minimum computer-system requirements for UC Surface, QMix-UC, and Studio One®.

    Mac

    Mac® OS X 10.8.5 64-bit or later

    Intel® Core™ 2 Duo processor (Intel Core i3 or faster recommended)

    4 GB RAM (8 GB or more recommended)

    Windows

    Windows® 7 x64/x86 SP1 + platform update, Windows 8.1 x64/x86, Windows 10 x64/x86

    Intel Core 2 Duo (Intel Core i3 or faster recommended)

    4 GB RAM (8 GB or more recommended)

    Mac and Windows Systems

    USB 2.0 port

    Internet connection

    Internal or external 7200 RPM storage drive highly recommended

    30 GB hard disk space

    Monitor with 1366x768 resolution

    iOS

    iOS 10 or later

    iPad Pro, iPad Air 2, iPad Air, iPad mini 4, iPad mini with Retina display, iPad (4th generation), iPad mini, iPad (3rd generation)

    Android

    Android™ 5.0 (Lollipop) or later

    Android smartphone (QMix-UC)

    Android tablet (8-inch) with 1024x768 resolution (UC Surface)

    ** Please note, system requirements may change. For the most recent system requirements please visit the manufacturer's official product listing **
