RA-DAN-TX
Radial Engineering DiNET DAN-TX - Dante Enabled DI Transmitter
The Radial DiNET DAN-TX is a 2-channel Dante™ transmitter for adding instrument or line level inputs to any Dante system.
Type: DI Boxes
-
-
Product Features:
Stereo analog input device for Dante networks
Connect instruments or line level sources
¼”, RCA and 3.5mm stereo TRS inputs
24bit/96kHz analog to digital conversion
-
Technical Specifications:
Specifications Audio circuit type: High current balanced active input device Number of channels: 2 Frequency response: 20Hz - 20kHz Dynamic range: >103dB Total harmonic distortion: 0.008% @ -6dBfs Intermodulation Distortion: 0.0017% -10dBfs Input Impedance: Unbal 240kΩ (20kΩ Line Mode), Bal 40kΩ, Noise: -98dB (EIN) Noise: 44.1kHz, 48kHz, 88.2kHz, and 96kHz (24bit) Features Input pad, HPF, Level Control Input Connectors: 1/4" TRS, 3.5mm & RCA Output Connectors: RJ45 Ethernet Extras: Instrument or Line Mode General Construction: 14-gauge steel Size (L x W x D): 5" x 3.31" x 1.88" (12.7cm x 8.4cm x 4.8cm) Weight: 1.45lb (0.66kg) Shipping size (L x W x D): 11.75" x 4.75" x 3" (29.8cm x 12.1cm x 7.6cm) Shipping weight: 2.1lb (0.95kg) Power: 15VDC 400mA (included) or PoE Conditions: For use in dry locations only between 5°C and 40°C Warranty: Radial 3-year, transferable
